Reliable Hydraulics, Proven Engineering
Based on the existing 2BV5 pump and compressor design, the 2BM5 vacuum pump and compressor offers proven performance and reliability to applications that require leak free performance.
Operates as a vacuum pump and compressor with a discharge pressure range of 33.4 psia (2.3 bar abs.)
Some applications require vacuum and compression in one process. Instead of handling the gas with two separate machines, our liquid ring vacuum pump and compressor models can do the job with only one pump - reducing cost and simplifying installation.
Safe Solution, No Leaks
Through a magnetic drive with static o-ring seals the 2BM5 leak free vacuum pump achieves non-contact torque transmission, allowing for a hermetically sealed pump body. This eliminates leaks, making the 2BM5 model an ideal solution for process applications that handle toxic or explosive gases or liquid, and applications that must comply with the strictest environmental regulations. ATEX Certified pumps are available.
